3 L 1500b / H Automatic Blowing Machine For Pet Bottle , PLC
Control
Product Description
Machine specification:
FP-6000-2 Automatic Plastic Bottle Blowing Machine is suitable for
blowing PET bottles of various shapes, volume from 100ml to 6000ml,
wide application for blowing mineral water bottles, soda bottles,
cola bottles..etc
1. Adopts advanced microcomputer control system, stable
performance, the conveyor automatically send embryo;
2, Use infrared heating lamps, penetrating power strong, embryo
heated while rotation, orbital revolution, heating uniformity,
rapid and reliable;
3, Light tube in heating area, reflector width and height can be
adjusted to suit the different structure preform heating, and
automatic exhaust temperature device in order to ensure constant
temperature of the drying tunnel;
4, Each machine has a safety self-locking device, when a processes
have problem, the program will automatically switch to a safe
state;
5, All the action drive by the cylinder, do not use pumps, with no
pollution, low noise;
6, Gas way design divide action and air blowing into three parts,
action to meet the needs of the different pressure of the blowing,
action;
7, Cooling system to achieve the desired cooling effect; H- the
bottle scrap rate less than 0.2%.
2,Features:
1. Produce bottle from 0.1L to 6L (2cavity)
2. Output capacity up to 1500 for 6L using two-cavity blow mould
3. Advanced PLC control system with a user-friendly panel and
time-control precision of PLC up to 0.01second
4. Equipped with special designed air storage unit
5. Using Infrared preform heater
6. Independent Temperature Control for different heating lamp to
get ideal preform heating results
7. Heating lamps are adjustable in directions to suit various
preforms.
8. Operated only by one person without special training.
9. Simple installation & startup adjustment.
10. Waste rate of finished bottle is less than 0.2%
Main parameter of the machine:
| Main paremeter |
| Model | FP-6000-2 |
| Container | Production material | PET |
| Volume | 0.1-6L |
| Theoretical output | 1300-1600PCS/H(6L) |
| Applicable bottle body diameter | 20-200mm |
| Applicable bottle neck | 25-58mm |
| Moulding | Max stretching distance | 350*460mm |
| Max. mould thickness | 305mm |
| Machine size and weight | Main machine(L*W*H) | 2250*2150*2200mm |
| Main machine weight | 5500kg |
| Preform unscrambler (L*W*H) | 2100*1000*2650mm |
| Heater weight | 450kg |
| Install Power-Using power | 66kw-36kw |
| N/M | item name | BRAND | ORIGINAL PLACE |
| 1 | PLC controller | DELTA | Taiwan |
| 2 | TOUCH SCREEN | DELTA | TAIWAN |
| 3 | Pneumatic components | FESTO | GERMANY |
| 4 | Pneumatic components | AIRTAC | TAIWAN |
| 5 | Photoelectric signal switching | OMRON | JAPAN |
| 6 | control button | OMRON | JAPAN |
| 7 | AIR FILTER | DELTA | TAIWAN |
| 8 | Electromagnetic valve | PMC | KOREA |
| 9 | High pressure muffler silencer | SMC | JAPAN |
Detailed Image
Packing & Delivery
Our Service
Customer's service:
1. FILL-PACK company can provide turn-key project for you, only you
have any idea to start beverage factory plant.
2. FILL-PACK company have professional design team, our engineer
can draw bottle samples and flow chart ofworkshop for you .
3. FILL-PACK company give you the best quotation for all kinds of
beverage production, only you can tell me whichkind of drink you
want to product, what is your capacity(how many bottles one hour)
what is you bottle material, pet or glass,etc
After service:
1. We send the engineers to help installing, commissioning and
training, the engineers start from our factory area.
2. We supply below necessary documents with the machine:
a. Machine layout
b. Electricity diagram
c. Machine certificate
d. General manual book/maintenance book
please kindly click the play button to watch the video
