Semi Automatic Juice Bottle Blowing Machine To Produce Heat
Resistant Bottles
Product Description
FP-1200R Juice Bottle Blowing Machine is suitable for producing PET
plastic containers and bottles from 10-1000ml. It is especially
used for hot fill bottles. Also it can be widely used to produce
the carbonated bottle, mineral water pesticide bottle, oil bottle
cosmetics, wide-mouth bottle etc.
● Adopting double crank to adjust mould, heavy locking mould,
stable and fast, Adopt infrared oven to heat the perform, the
perform rotated and heated equally.
● The air system has been divided into two parts: pneumatic action
part and bottle blow part to meet the different requirements for
the action and blow. It can provide sufficient and steady high
pressure for blowing large irregular shaped bottles.
● The machine is also equipped with muffler and oiling system to
lubricate the mechanical part of the machine.
● The machine can be operated in the step-by-step mode and the
semi-auto mode.
● The machine is small with low in vestment, easy and safe to
operate.
★This machine can producing PET bottle which can resist high
temperature, such like 92 centigrade degree. This has solved the
problem of the traditional juice and other liquid food packing.
Main parameter of the machine:
| Main paremeter |
| Model | FP-1200R Hot filling |
| Container | Production material | PET |
| Volume | 0.1-6L |
| Theoretical output | 600-800PCS/H(6L) |
| Preform length | 15-350mm |
| Preform inner diameter | 5mm-38mm |
| Moulding | Max.mould plate Dimenstion(L*W) | 350*380mm |
| Max. mould thickness | 180mm |
| Clamping force | 45KN |
| Mould opening stroke | 160mm |
| Machine size and weight | Main machine(L*W*H) | 1650*650*1600mm |
| Main machine weight | 500kg |
| Heater(L*W*H) | 1800*700*1600mm |
| Heater weight | 250kg |
| Power | 24.8kw
|
Features:
1) Juice bottle blowing machine has a external machinery--mold
temprature control.Which can heat the blower through electrical
temperature or oil temperature and improve heat resistance of the
bottle..
2)The theoretical output is 600pcs/H.
3)Juice bottle blowing machine is suitable to different produce
shap of PET.
4) Max.container volume is 1.5l (2 cavities).
5) It is also widely used to produce mineral water
bottles,carbonate soft drink bottles,juice bottles,medical
bottles,cosmetic and oil bottles etc.
Mould heater
| Heat transfer media: heat transfer fluid | Maximum temperature: 200℃ |
| Heat media inlet & outlet: 3/8”mm | Actual cooling capacity: 2000Kcal/h |
| Heat ingbarrel: iron | Heating wire: 304 stainless steel |
| Overall dimension: 739*310*643mm | Net weight: 52kg |
| Temperature error: ±1℃ | Microcomputer board error:±0.5℃ |
| Pipe type: teflon pipe | Number of interface: two in and two out(can be customized) |
Detailed Image
Packing & Delivery
Our Service
Customer's service:
1. FILL-PACK company can provide turn-key project for you, only you
have any idea to start beverage factory plant.
2. FILL-PACK company have professional design team, our engineer
can draw bottle samples and flow chart ofworkshop for you .
3. FILL-PACK company give you the best quotation for all kinds of
beverage production, only you can tell me whichkind of drink you
want to product, what is your capacity(how many bottles one hour)
what is you bottle material, pet or glass,etc
After service:
1. We send the engineers to help installing, commissioning and
training, the engineers start from our factory area.
2. We supply below necessary documents with the machine:
a. Machine layout
b. Electricity diagram
c. Machine certificate
d. General manual book/maintenance book
