2 Cavity 1.5l Full Automatic Pet Bottle Manufacturing Machine To
Produce Carbonated Beverage Bottle
Product Description
FP-2000 is the fastest liner blow molding machine in mainland of
China by now. FP-2000 reaches around 2000BPH for 1.5 L bottle. Its
baking tunnel is separated from the blow station so that time for
mold opening is shortened with a result of speedy blowing and high
output, damage to machine is lessened so as to keep reliable
performance and prolong service life, as well as machine runs more
smoothly and steadily.
FP-2000 is controlled by PLC. The whole process from preform
feeding to bottle discharging is completed automatically with
advantages of labor saving and no pollution. FP-2000 consists of
three main parts: preform loading system, Heater channel & blow
station.
MACHINE FEATURES:
1. Machine use of advanced PLC control system , stable in
performance, automatic preform feeding .
2. Strong penetrability and good and swift distribution of the heat
by letting the bottles rotate by itself and revolute in the rails
simultaneously in the infrared preheater
3. High adjustability to enable the preheater to preheat preforms
in shapes by adjusting the light tube and the length of the
reflecting board in the preheating area, and eternal temperature in
the preheater with an automatic thermostatic apparatus.
4. High safeties with security automatic-locking apparatus in each
mechanical action, which will make the procedures turn into a state
of safety in case of a breakdown in certain procedure.
5. No contamination and low noise with the air cylinder to drive
the action instead of the oil pump.
6. Air route design is divide into two parts ,
7. Ideal effect of the chilling with the chilling system
8. Low rejection rate: less than 0.3percent
| Main parameter |
| Model | FP-2000 |
| Container | Product material | PET |
| Volume | 0.1L-2L |
| Theoretical output | 2000-2400PCS/H(0.5L) |
| Applicable bottle body diameter | 20-92mm |
| Applicable bottle height | 50-350mm |
| Moulding | Max.mould plate Dimenstion (LxW) | 450x490mm |
| Max.mould thickness | 180mm |
| Machine size and weight | Main machine (L×W×H) | 2500*1650*1850mm |
| Main machine weight | 3200Kg |
| Preform unscrambler (LxWxH) | 2000*950*2480mm |
| Heater weight | 250Kg |
| Install Power-Using power | 18kw
|
Packing & Delivery
1. the Bottle Blowing Machine Factory is packed by wooden case.
2. The delivery date of Bottle Blowing Machine Factory is within 30
days after payment.
Our Service
1.installation&commissioning
After the equipment arrived at the customer's site. the customer is
responsible for unpacking and arranging the equipment according to
the placement drawing;Our technician will do equipment set up and
commissioning,buyer should offer necessary help if needed
2.Training
We are responsible for offering the technical training to
user.Through training,users' technical staff can grasp and the
skill of operation and maintenance proficiently.The buyer also can
send staff to our company for learning.
3.Quality assurance
The warranty period is 12 months after acceptance chech of the
production line.if there is any different between the furnished
equipment in the customer's factory and the equipment concerned in
the contract.
