Powder Concentrate Juice Processing Machine Electric Driven For
Sterilizing Juice
Model Number: MT-2
Application: Bottled and canned juice
Automatic grade: automatic
Packaging Type: Bottle or can.
Power: Specified as machine
Driven type: Electric
Certification: CE, ISO
Guarantee time: 1 year
Condition: New
Voltage: Customised
Quick Detail:
1. Capacity: 2000L/H
2. For mixing and sterilizing juice
3. Main material: SUS304 / SUS316
4. Treating from the fruit juice powder.
Description:
The follow juice processing line is used to mix the juice powder
for juice drink, and then make filter, homogenizer and
sterilization for bottle or can filling.
1. Juice mixing tank:
The tank is all made of SUS304 material, is mainly used to mix
syrup, juice powder and water for juice drink with the motor
driving stirring function. Normally it’s single layer without
heating and cooling function, if need heating function, we can also
make it. You can manual put the material into tank for mixing, or
pumped by the pump.
2. Double filter:
This machine is used to remove and purify every kind of solid
impurity which is invisible to the naked eye in the fresh milk,
sugar solution and beverage. Two pieces of filter alternate to use,
it could change the filter cloth without stopping the machine and
is suitable for long term continuous production.
3. High pressure homogenizer:
This machine is mainly used to break, homogenizing and emulsify
fluid mixing materials (liquid mix liquid or liquid mix solid).
Main function of homogenizer include: improve homogeneity and
stability of products, increase the period of maintenance and
reduce reaction time, so as to save the mass of activator and
color. It is the ideal machine to micromaching liquid for juice,
milk, sugar, food, chemical, pharmaceutical and microbial industry.
4. Ultra high temperature instantaneous sterilizer
This ultra high temperature instantaneous sterilizer is suitable
for sterilizing the liquid material, such as juice, fresh milk,
fruit milk, tea, wine, soybean milk and Chinese medicine, as well
as the sticky material (for example, sweat condensed milk). It is
with coil tube type heating system, heated by steam, so here you
need to set with a steam boiler or other machine for supplying
needed steam.
After this machine, the juice can be stored in a tank or connect
the filling machine directly, which is hot juice for filling.
please kindly click the play button to watch the video
