    Semi Auto Mineral Water Stretch Bottle Blow Making Machine / Equipment / Line / Plant / System

    Ask Lasest Price
    Brand Name : FillPack
    Model Number : FP-1200B
    Certification : CE. ISO9001
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, , MoneyGram
    Supply Ability : 1 set / month
    Delivery Time : 35-40 days after deposit receipt
    • Product Details
    • Company Profile

    Semi Auto Mineral Water Stretch Bottle Blow Making Machine / Equipment / Line / Plant / System


    1+2 PET bottle blow molding machine

    >>> Product Introduction:
    FP-1200B semiautomatic bottle blow molding machine is suitable for producing PET plastic containers and bottles from 10-2000ml. It is widely used to produce the carbonated bottle ,mineral water, carbonated drink bottle, pesticide bottle oil bottle cosmetics, wide-mouth bottle etc.

    >>> Product Features:

    ● The machine can be operated in the step-by-step mode and the semi-auto mode.

    ● The machine is small with low investment, easy and safe to operate.

    ● Adopting double crank to adjust mould ,heavy locking mould, stable and fast ,Adopt infrared oven to heat the perform ,the perform rotated and heated equally.

    ● The air system has been divided into two parts: pneumatic action part and bottle blow part to meet the different requirements for the action and blow .It can provide sufficient and steady high pressure for blowing large irregular shaped bottles.

    >>> Flow and Auxiliary machines:
    HP Air Compressor → Air Tank → Air Filter →Air Dryer → Air Filter → Chiller → LP Air Compressor →Automatic Bottle Blowing Machine
    1. Bottle Preform If you need, we can also help you find the bottle preform in china.
    2. PET Bottle Mold Our PET blowing machine can produce various shape bottles. we can according to your need to design your own bottle and make mold for you.

    >>> Technical Paramters:

    Container
    Product material
    PET,PP,PE
    Volume
    0.1L-2L
    Output
    2400BPH
    Preform length
    15-350mm
    Preform inner diameter
    Φ5-38
    Moulding
    Max.mould plate Dimenstion
    350×380mm
    Max.mould thickness
    180
    Clamping force
    45
    Machine size and weight
    Main machine
    160×60×161cm/500Kg
    Heater
    187×63×145cm/250Kg
    Power
    17.5kw
